Arne S
Small and flexible
With a great variety of adjustable supports for installation on columns, walls or catenaries, and a light that can be varied in terms of intensity, color, governance or degree of dispersion or concentration, the Arne S urban floodlight represents a flexible, energy efficient solution for highlighting the best paths or monuments. It also has two lighting alternatives: a technical one and a decorative one.
Materials
AISI304 stainless steel flange and anodised injected aluminium EN-AC-47100 bracket with protection powder-coated.
A2 stainless steel hardware.
Column made from hot-dip galvanized S-275 JR Class 1 steel, painted finish: 3.60 m, 4.40 m, 5.20 m and 6.00 m heights with one circular section segment of Ø114.3 mm.
Installation
Column fixed in a concrete block on-site, with a groove for electrical connection, and four anchor bolts per column, 20 cm below the pavement level.
Installation and assembly instructions, screws, template, and anchor bolts included.
Weight
Single column accessory: 0.8
*Approximate weight without packaging (kg)
:DIMENSIONS
